M109 - Vacuum Cleaner Galaxy

(Ivor Trueman)
Cropped close-up (Ivor Trueman)
Cropped (James Clark)
(James Clark - 700mm)

Information...

M109 is a barred spiral galaxy in Ursa Major, which lies approx. 83 million light years away, making it the most distant object in the Messier catalogue..

About half of all spiral galaxies are thought to be barred, including our own Milky Way. M109 is unusual because it has Ansae bars at each end of the 'barre', which are not usually seen in Sc type spiral galaxies, where the arm structure is still well defined.

In James Clark's 700mm focal length image, NGC3953 can also be seen bottom-left, and the fainter galaxy towards the upper middle of the image (PGC37735) is approx 52 million light years away.

For more info. see the Wikipedia entry and the Deep Sky Video for M109.



×

Map

×

Measuring Angles

Hold your arm at full length, then close one eye & use the hand shapes shown above to measure the angular distance between the stars.

(Ain't anatomy wonderful!)

×

Apparent Magnitude

The apparent magnitude of a star is a measure of how bright it appears from Earth. The scale was introduced over 2,000 years ago by the Greek astronomer Hipparchus, who grouped stars into six categories. The brightest 20 or so were deemed to be 'first magnitude', slightly dimmer stars 'second magnitude', and so on until the barely visible stars were classed as 'sixth magnitude'.

Later it was recognised that our eyesight, once it has been given time to get used to darkness, has a logarithmic response. i.e. a Mag. 1 star is actually 2.512 times brighter than a Mag. 2 star, or 6.310 times brighter than a Mag. 3 star (2.512 x 2.512 = 6.310).

The six Magnitudes thus corresponds to a 2.5126 difference in brightness or 100x.

Apparent magnitude

Today the scale has now been extended, so that brighter objects can have an apparent magnitude of 0 or even negative. The brightest star Sirius, for example, has an apparent magnitude of -1.44 and the Sun is a whopping -26.74, due to it's close proximity to Earth.
